| Specification | |
|---|---|
| Item | Motherboard |
| Model | H61M-DS2 |
| Brand | Gigabyte |
| Motherboard Type | Standard |
| Chipset | Intel H61 Express Chipset |
| Supported Processors | 2nd & 3rd Generation processor 1155 Socket |
| Max Memory | 16 GB |
| Onboard Video | Yes |
| Onboard Audio | Realtek ALC887 Audio Codec High Definition Audio 2 / 4 / 5.1/7.1-Channel |
| Onboard LAN | 1 x Atheros GbE LAN chip (10/100/1000 Mbit) |
| Connectors | 1 x 24-pin ATX Main Power Connector 1 x 4-pin ATX 12V Power Connector 4 x SATA 3Gb/s Connectors 1 x CPU Fan Header 1 x System Fan Header 1 x Front Panel Header 1 x Front Panel Audio Header 2 x USB 2.0/1.1 Headers 1 x Parallel Port Header 1 x Serial Port Header 1 x clearing CMOS Jumper |
| Other Features | Support for DDR3 1333 / 1066 / 800 MHz Memory Modules |
Gigabyte GA-H61M-DS2 motherboard has 3rd Gen Intel 22nm CPUs and 2nd Gen Intel Core CPUs LGA1155 socket support, ultra-durable 4 classic design, unique on / off charge, touch BIOS, enhanced Intel HD graphics, innovative smart 6 technology for smarter PC management, DualBIOS protection, short circuit protection, electrostatic protection, power failure protection, high-temperature protection, onboard HD audio & video, 4 x SATA 3Gb/s connectors supporting up to 4 SATA 3Gb/s devices storage interface.
1 review for Gigabyte H61M-DS2 2nd & 3rd Gen Motherboard
Good Product
